Cisco ISR4331/K9 4331 Integrated Services Router
ISR 4331 Integrated Services Router from Cisco. Boasting an aggregate data throughput of up to 100 Mb/s that's upgradeable to up to 300 Mb/s, ISR 4331 router is equipped with a total of three WAN/LAN ports, including one Gigabit Ethernet RJ45/SFP port, a Gigabit Ethernet RJ45 port, and a Gigabit SFP port, along with a mini-USB port, a USB 2.0 Type-A port, two NIM (network interface module) slots, and one enhanced service module slot.
The ISR 4331 makes use of Cisco's Software Defined WAN, designed to intelligently route network data over the most optimal links, while offering control over application performance, bandwidth, privacy and WAN link availability. Cisco ISR4331/K9 4331 Integrated Services Router also employs Cisco's intent-based Digital Network Architecture (DNA) to interpret and analyze network data, helping to boost security and identify potential network issues.
Cisco ISR4331-SEC/K9 Specs
Interfaces
| Ports |
1 x 10/100/1000 Mb/s Gigabit Ethernet RJ45 1 x 10/100/1000 Mb/s Gigabit SFP 1 x 10/100/1000 Mb/s Gigabit Combo Ethernet/SFP 1 x Ethernet RJ45 (Console) 1 x Ethernet RJ45 1 x Mini-USB 1 x 480 Mb/s USB Type-A |
Computer
| Flash Memory |
4 GB |
| Memory |
4 GB DDR3 |
Electrical
| Power Draw |
530.00 W |
| AC Input Power |
100 to 240 VAC, 50 / 60 Hz at 1.3 to 3 A |
| PoE Power Budget |
530 W |
Environmental
| Operating Temperature |
32 to 104°F / 0 to 40°C |
| Operating Humidity |
5 to 85% |
| Operating Altitude |
0 to 10,000' / 0 to 3050 m |
| Storage Temperature |
-40 to 158°F / -40 to 70°C |
| Storage Humidity |
5 to 95% |
| Storage Altitude |
15,584' / 4750 m |
| Noise Level |
81.6 dB (Active) |
| Certifications |
CAN/CSA, EN 60950-1, UL, as per Manufacturer |
General
| Mean Time Between Failures (MTBF) |
587,250 Hours |
| Rack Form Factor |
1 RU |
| Dimensions |
1.75 x 17.25 x 17.25" / 44.45 x 438.15 x 438.15 mm |
| Weight |
16.1 lb / 7.3 kg |
Packaging Info
| Package Weight |
19.3 lb |
| Box Dimensions (LxWxH) |
23.1 x 23 x 6.9" |
