SecuGen Hamster Pro 20 HU20-AL Type C Fingerprint Reader

The SECUGEN HU20-AL Type C is a compact optical fingerprint reader for identity checks, user authentication and biometric software projects. It suits businesses that need fingerprint capture for staff, customers or authorised system users. Moreover, its small housing fits desks and service counters without taking up much space. With compatible software, it supports fingerprint identification and verification in everyday business workflows.

Product Overview

This desktop biometric scanner captures fingerprint images at 500 dots per inch (DPI), providing detail for compatible matching software. In addition, its low-profile housing gives users easy access to the scanning surface.

The reader uses a Universal Serial Bus (USB) connection for data and power. Meanwhile, SecuGen software development kits (SDKs) help developers build fingerprint registration and matching into supported applications. Auto-On and Smart Capture require compatible software integration.

Key Features

• Automatic finger detection: Auto-On detects finger placement in supported applications, simplifying the scanning process.

• Adaptive capture: Smart Capture adjusts scanning for dry, moist, aged or scarred fingers, helping handle difficult fingerprints.

• Durable scanning surface: The glass platen resists scratches and impact, supporting repeated use.

• USB power: Power comes from the connected host, reducing the need for separate power connections.

• Compact design: The small housing fits workstations where desk space matters.

Technical Specifications

• Brand: SecuGen

• Model: HU20-AL

• Sensor: U20-AL optical contact sensor

• Resolution: 500 DPI

• Image size: 300 × 400 pixels

• Grayscale: 256 levels, 8-bit

• Smart Capture speed: 0.2–0.5 seconds

• Interface standard: USB 2.0 Hi-Speed

• Power supply: 5 V via USB

• Maximum current: 130 mA

• Dimensions: 53.9 × 58.5 × 31.6 mm

• Weight: 98 g

• Cable length: 1,500 mm

• Dust and water resistance: IP54

• Operating temperature: −20°C to 65°C

• Manufacturer warranty: One-year limited warranty

Common Applications

The SECUGEN HU20-AL Type C suits staff attendance projects, financial systems and medical information applications when paired with suitable software. Furthermore, organisations can integrate this optical fingerprint scanner into supported computer and network authentication workflows.

Why Choose This Product?

The SECUGEN HU20-AL Type C combines a compact footprint with a durable sensor and software integration options. Moreover, SecuGen development tools support fingerprint registration and matching, helping teams add biometric functions to business applications. It provides a practical capture device for organisations building compatible identity verification systems.

Frequently Asked Questions

Which driver supports biometric login with the SECUGEN HU20-AL Type C?

SecuGen lists the HU20-AL under its Windows Biometric Framework (WBF) drivers. The required biometric service must also be enabled on the host.

Why might biometric login require extra setup on a server?

The biometric service may be disabled by default on supported server operating systems. Therefore, administrators should check the service before using the WBF driver.

How can installers check fingerprint capture before configuring their application?

SecuGen’s diagnostic utility checks the reader connection and fingerprint capture. Additionally, it offers scanning adjustments to help assess basic device operation.
